| . . | 24100J20926F1 | [1] | HYD LINES ASSY, REWORK UPPER (AUXILIARY) (F1 ONLY) | |
| . . | 24100J20926F2 | [1] | HYD LINES ASSY, REWORK UPPER (AUXILIARY & BREAKER) (F2 ONLY) | |
| 1. | 2416T28821 | [1] | SUPPORT | KOB(F2 ONLY) |
| 2. | ZC26X22011 | [2] | CLAMP | KOBSingle Line -- 38x29x65mm Long, (F2 Only) |
| 3. | 2432P2450 | [1] | LABEL | KOB(F2 ONLY) |
| 4. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm, (F2 Only) Superseded by part number: ZW26X10000 |
| 5. | ZS13C10050 | [2] | SCREW | KOBM10x1.50x50mm, (F2 ONLY) Superseded by part number: ZS18C10050 |
| 6. | 2444Z4645 | [2] | ELBOW | KOB(F1 ONLY) |
| 7. | 2444R3146 | [1] | HOSE | KOB(F1 ONLY) |
| 8. | 2444R3147 | [1] | HOSE | KOB(F1 ONLY) |
| 9. | ZA33F28016 | [1] | ELBOW | KOB(F2 ONLY) |
| 10. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 11. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm, (F2 Only) |
| 12. | ZW13H08000 | [4] | WASHER | KOB(F2 ONLY) |
| 13. | ZN13C08007 | [8] | NUT | KOBM08x1.25mm, (F2 Only) Superseded by part number: ZN18C08007 |
| 14. | 2420T2948D14 | [1] | U-BOLT | KOB(F2 ONLY) |
| 15. | 2420T2948D13 | [1] | U-BOLT | KOB(F2 ONLY) |
| 16. | 2446U233F1 | [1] | FILTER ASSY | KOB(F2 ONLY) |
| 16-1. | 2446U232S1 | [1] | COVER | KOB(F2 ONLY) |
| 16-2. | 2446U232S2 | [1] | ELEMENT | KOBASSY (F2 ONLY) Superseded by part number: 2446U233S2 |
| 16-3. | 2446U232S3 | [1] | CASE | KOB(F2 ONLY) |
| 16-4. | 2446U233S4 | [1] | PLUG 9F2 ONLY) | |
| 16-5. | 2446U233S5 | [1] | VALVE (F2 ONLY) | |
| 16-6. | 2446U233S6 | [1] | SPRING (F2 ONLY) | |
| 16-7. | 2446U233S7 | [1] | PLUG | KOB(F2 ONLY) |
| 16-8. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm, (F2 Only) |
| 16-9. | ZD12G11500 | [1] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBID 114.40 ± 0.94 x OD 120mm, (F2 Only) |
| 16-10. | ZD11P05000 | [1] | O-RING | KOB(F2 ONLY) |
| 16-11. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm, (F2 Only) |
| 16-12. | 2446U233S12 | [1] | SCREW | KOB(F2 ONLY) |
| 16-13. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm, (F2 Only) |
| 17. | 2436U1310F1 | [1] | VALVE | KOBASSY (SEE CPM) (F2 ONLY) |
| 18. | 2418T16751 | [1] | TUBE | KOB(F2 ONLY) |
| 19. | 2418P29579 | [1] | RIGID TUBE | KOB(F2 ONLY) |
| 20. | 2418P29801 | [1] | TUBE | KOB(F2 ONLY) |
| 21. | 2418P29802 | [1] | TUBE | KOB(F2 ONLY) |
| 22. | 2416T13250 | [1] | U-BRACKET | KOB(F2 ONLY) |
| 23. | 2444Z2348 | [2] | HYD CONNECTOR | KOB(F2 ONLY) |
| 24. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long, (F2 ONLY) |
| 25. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm, (F2 Only) |
| 26. | ZA23B22028 | [1] | CONTROL | KOB(F2 ONLY) |
| 27. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm, (F2 Only) |
| 28. | ZS18C12110 | [2] | SCREW,Hex, M12 x 110mm | KOBM12x1.75x110mm, (F2 Only) |
| 29. | ZW26X12000 | [6] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm, (F2 Only) |
| 30. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm, (F2 Only) |
| 31. | 2444R3196 | [1] | HOSE | KOBHOSE (F2 ONLY) |
| 32. | 2444R3197 | [1] | HOSE | KOBHOSE (F2 ONLY) |
| 33. | 2418T22217 | [1] | TUBE | KOB(F2 ONLY) |
| 34. | 2418T22216 | [1] | TUBE | KOB(F2 ONLY) |
| 35. | 2444Z2236 | [2] | HYD CONNECTOR | KOB(F2 ONLY) |
