神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-001[01]) - VALVE ASSY, CONTROL (2436U2905F1 & 2436U2905F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
536 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2905F1 | [1] | CONTROL VALVE | KOBMAIN, Page 1 of 2 Superseded by part number: 2436U2905F2 |
| . . | 2436U2905F2 | [1] | CONTROL VALVE | KOBMAIN |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 151. | 2436U1219S153 | [1] | PLUG | KOB |
| 153. | 2441U732S461 | [4] | PLUG | KOBPLUG Superseded by part number: 2436U2080S8 |
| 155. | 2436U1207S851 | [3] | PLUG | KOB |
| 156. | 2436U1165S156 | [1] | PLUG | KOB |
| 159. | 2436R885S13 | [4] | ORIFICE | KOB |
| 165. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 166. | ZD12P01100 | [5] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 167. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 201. | 2436U2631S201 | [3] | COVER | KOB |
| 202. | 2436U1439S202 | [2] | COVER | KOB |
| 203. | 2436U1265S203 | [5] | COVER | KOB |
| 251. | 2436U1165S251 | [5] | PLUG | KOB |
| 261. | 2436U1457S162 | [5] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 263. | ZD12G03500 | [5] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 265. | ZD12G02500 | [5] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 301. | 2436U2631S301 | [2] | SPOOL | SPOOL |
| 302. | 2436U2869S302 | [1] | SPOOL | KOB |
| 303. | 2436U2869S303 | [1] | SPOOL | KOB(BOOM) |
| 304. | 2436U2869S304 | [1] | SPOOL | KOB(BUCKET) |
| 305. | 2436U1330S305 | [1] | SPOOL | KOB(PRES. TRAVEL) |
| 306. | 2436U1454S306 | [2] | SPOOL | KOB(BYPASS CUT) |
| 307. | 2436U1265S307 | [2] | SPOOL | KOB(CONFLUENCE) |
| 320. | 2436U2631S320 | [2] | SPRING | KOB(TRAVEL INNER) |
| 321. | 2436U2634S321 | [2] | SPRING | KOB(TRAVEL OUTER) |
| 322. | 2436U1265S322 | [3] | SPRING | KOB(RETURN) |
| 323. | 2436U1265S327 | [3] | SPRING | KOB(RETURN) |
| 324. | 2436U1265S324 | [1] | SPRING (PRES. TRAVEL) | SPRING (PRES. TRAVEL) |
| 326. | 2436U1265S326 | [2] | SPRING | KOB(CUT VALVE OUTER) |
| 327. | 2436U1454S327 | [2] | SPRING | KOB(ARM CONFLUENCE) |
| 328. | 2436U1265S328 | [2] | SPRING | KOB(CUT VALVE INNER) |
| 332. | 2436U1265S332 | [8] | SPRING SEAT | KOB |
| 335. | 2436U1265S335 | [3] | STOP | KOB |
| 336. | 2436U1265S336 | [3] | BOLT | KOB |
| 337. | 2436U1265S337 | [3] | ROD | KOB |
| 338. | 2436U1265S338 | [2] | ROD | KOB |
| 341. | 2436U1439S341 | [2] | SPRING SEAT | KOB |
| 345. | 2413U181S335 | [2] | STOP | KOB |
| 346. | 2436U1439S346 | [2] | BOLT | KOB |
| 511. | 2436U1265S511 | [8] | POPPET | KOB |
| 521. | 2436U1265S521 | [9] | SPRING | KOB |
| 542. | 2436U1265S542 | [3] | SEAT/SLOT | KOB |
| 543. | 2436U1265S543 | [1] | SEAT/SLOT | KOB |
| 551. | 2436U1454S551 | [11] | PLUG | KOB Superseded by part number: 2436U1265S551 |
| 561. | ZD12P02000 | [11] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 602. | 2436R683F3 | [2] | VALVE | KOBSee Figure 12-002 |
| 701. | 2436U2584F1 | [1] | X | KOBSee Figure 12-001-01 |
| 957. | 2436U1170S14 | [2] | PIN | KOBPIN |
| 971. | 2436U1265S971 | [1] | CAPSCREW (M14X70mm) | |
| 972. | 2436U1265S972 | [1] | CAPSCREW (M14X70mm) | |
| 973. | 2436U1265S973 | [2] | CAPSCREW (M14X55mm) | |
| 974. | 2436U1265S974 | [1] | CAPSCREW (M14X55mm) | |
| 975. | 2436U1265S975 | [1] | CAPSCREW (M14X30mm) | |
| 976. | 2436U1265S976 | [1] | CAPSCREW (M14X80mm) | |
| 991. | NA | [1] | NOT SERVICED | FORNameplate |
| . . | 2436U2869R120 | [1] | FIXING PLATE | KOBREPAIR KIT, VALVE (ARM, LEFT TRAVEL SEC) |
| . . | 2436U2869R130 | [1] | SPOOL | KOBSPOOL (ARM) |
| . . | 2436U2869R140 | [1] | SPOOL | KOBSPOOL (BOOM) |
| . . | 2436U2869R150 | [1] | SPOOL | KOBSPOOL (BUCKET) |
