神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-001[02]) - VALVE ASSY, CONTROL (2436U2905F1 & 2436U2905F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
675 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2905F1 | [1] | CONTROL VALVE | KOBMAIN, Page 2 of 2 Superseded by part number: 2436U2905F2 |
| . . | 2436U2905F2 | [1] | CONTROL VALVE | KOBMAIN |
| 10. | 2436U2905S10 | [2] | VALVE, PRESSURE RELI | KOBEF F2 ONLY |
| 152. | 2436U1165S152 | [19] | PLUG | KOB |
| 153. | 2441U732S461 | [4] | PLUG | KOBPLUG Superseded by part number: 2436U2080S8 |
| 154. | 2436U1165S154 | [7] | PLUG | KOB |
| 157. | 2436U1165S157 | [2] | PLUG | KOB Superseded by part number: 2436U1265S157 |
| 158. | 2436U1207S155 | [7] | PLUG | KOB |
| 159. | 2436R885S13 | [4] | ORIFICE | KOB |
| 161. | ZD12G03000 | [7] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 162. | ZD12P01000 | [26] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 164. | ZD12P01400 | [7] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 166. | ZD12P01100 | [5] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 168. | ZD12P00800 | [7] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 251. | 2436U1165S251 | [5] | PLUG | KOB |
| 273. | ZS23C08025 | [20] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 307. | 2436U1265S307 | [2] | SPOOL | KOB(CONFLUENCE) |
| 308. | 2436U2529F1 | [1] | VALVE PRESSURE RELIE | KOBSee Figure 12-007 |
| 327. | 2436U1454S327 | [2] | SPRING | KOB(ARM CONFLUENCE) |
| 337. | 2436U1265S337 | [3] | ROD | KOB |
| 351. | 2436U1304S351 | [1] | ORIFICE | KOB Superseded by part number: 2436U1165S351 |
| 512. | 2483U172S19 | [6] | BALL | KOB |
| 513. | 2436U2634S513 | [1] | POPPET | KOB |
| 521. | 2436U1265S521 | [9] | SPRING | KOB |
| 542. | 2436U1265S542 | [3] | SEAT/SLOT | KOB |
| 544. | 2436U1439S544 | [2] | SEAT | KOB |
| 551. | 2436U1454S551 | [11] | PLUG | KOB Superseded by part number: 2436U1265S551 |
| 552. | 2436U585S651 | [13] | PLUG | KOB Superseded by part number: YT30V00009S153 |
| 561. | ZD12P02000 | [11] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 601. | 2436R839F4 | [2] | VALVE | KOBSee Figure 12-006, F1 ONLY |
| 602. | 2436R683F3 | [2] | VALVE | KOBSee Figure 12-002 |
| 604. | 2436R768F3 | [6] | VALVE PRESSURE RELIE | KOBSee Figure 12-001-02 Superseded by part number: 2436R837F3 |
| 611. | 2436R769F1 | [2] | VALVE | KOBRELIEF, See Figure 12-003 |
| 612. | 2436U1454S612 | [1] | POPPET | KOB |
| . . | 2436U2869R120 | [1] | FIXING PLATE | KOBREPAIR KIT, VALVE (ARM, LEFT TRAVEL SEC) |
| . . | 2436U2869R130 | [1] | SPOOL | KOBSPOOL (ARM) |
| . . | 2436U2869R140 | [1] | SPOOL | KOBSPOOL (BOOM) |
| . . | 2436U2869R150 | [1] | SPOOL | KOBSPOOL (BUCKET) |
