现代零件查询R320LC-7 BUCKET(2.1M3 SAE HEAPED, LIGHT DUTY)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
289 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
61N9-30500
|
[1] |
BUCKET ASSY
|
|
| . |
61N9-30501
|
[1] |
BUCKET ASSY
|
|
| . |
61N9-30501BG
|
[1] |
BUCKET ASSY
|
|
| 1. |
61N9-35010
|
[1] |
BUCKET WA
|
|
| 1. |
61N9-35011
|
[1] |
BUCKET WA
|
|
| 1. |
61N9-35011BG
|
[1] |
BUCKET WA
|
|
| 1-1. |
E262-3027
|
[6] |
ADAPTER-TOOTH
|
|
| 1-1. |
61N8-31320
|
[6] |
ADAPTER-TOOTH
|
|
| 2. |
E262-3046
|
[6] |
POINT-TOOTH
|
|
| 2. |
61N8-31310
|
[6] |
POINT-TOOTH
|
|
| 2. |
61N8-31310BG
|
[6] |
POINT-TOOTH
|
|
| 3. |
63E1-3533
|
[1] |
SIDE CUTTER-LH
|
|
| 3. |
63E1-3533BG
|
[1] |
SIDE CUTTER-LH
|
|
| 4. |
63E1-3534
|
[1] |
SIDE CUTTER-RH
|
|
| 4. |
63E1-3534BG
|
[1] |
SIDE CUTTER-RH
|
|
| K5. |
E262-5004
|
[6] |
PIN-TOOTH
|
|
| 6. |
61E5-1126
|
[1] |
BUSHING
|
|
| 8. |
61E5-3136
|
[1] |
COVER PLATE
|
|
| 9. |
S017-160502
|
[2] |
BOLT-HEX
|
|
| 10. |
S017-220652
|
[4] |
BOLT-HEX
|
|
| 11. |
S017-220702
|
[6] |
BOLT-HEX
|
|
| 12. |
S205-221002
|
[10] |
NUT-HEX
|
|
| 13. |
S411-160002
|
[3] |
WASHER-SPRING
|
|
| 14. |
S411-220002
|
[10] |
WASHER-SPRING
|
|
| 14. |
S441-220006
|
[10] |
WASHER-HARDENED
|
|
| K15. |
61E5-11150
|
[6] |
WASHER-LOCK
|
|
| 16. |
61E5-3141
|
[6] |
SHIM(1.0T)
|
|
| K. |
E262-5004-S
|
[1] |
TOOTH PIN KIT
|
|
