现代零件查询R320LC-7 BUCKET(1.44M3 SAE HEAPED, HEAVY DUTY)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
642 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
61N9-30600
|
[1] |
BUCKET ASSY
|
|
| . |
61N9-30601
|
[1] |
BUCKET ASSY
|
|
| . |
61N9-30601BG
|
[1] |
BUCKET ASSY
|
|
| . |
61N9-30602BG
|
[1] |
BUCKET ASSY
|
|
| 1. |
61N9-36010
|
[1] |
BUCKET WA
|
|
| 1. |
61N9-36011
|
[1] |
BUCKET WA
|
|
| 1. |
61N9-36011BG
|
[1] |
BUCKET WA
|
|
| 1. |
61N9-36012BG
|
[1] |
BUCKET WA
|
|
| 1-1. |
61E7-0100
|
[5] |
ADAPTER-TOOTH
|
|
| 1-1. |
61NA-31320
|
[5] |
ADAPTER-TOOTH
|
|
| 2. |
61E7-0101
|
[5] |
POINT-TOOTH
|
|
| 2. |
61NA-31310
|
[5] |
POINT-TOOTH
|
|
| 2. |
61NA-31310BG
|
[5] |
POINT-TOOTH
|
|
| 3. |
61E7-0105
|
[5] |
PIN-TOOTH
|
|
| 3. |
61E7-0105
|
[5] |
PIN-TOOTH
|
|
| 4. |
61E5-1126
|
[1] |
BUSHING
|
|
| 5. |
61E5-3136
|
[1] |
COVER PLATE
|
|
| 6. |
S017-160502
|
[2] |
BOLT-HEX
|
|
| 7. |
S411-160002
|
[3] |
WASHER-SPRING
|
|
| 8. |
61EH-11150
|
[5] |
WASHER-LOCK
|
|
| 9. |
61E5-3141
|
[6] |
SHIM(1.0T)
|
|
