纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.043.01[00]) - VALVE ASSEMBLY, RELIEF (YN23V00003F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
343 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN23V00003F1 | [1] | PRESSURE RELIEF VALVE | KOB |
| 1. | NA | [1] | NOT SERVICED | FORHousing |
| 7. | 2436U388S42 | [1] | O-RING | KOB |
| 10. | ZD12P02100 | [1] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOBO-Ring -- ID 20.80 ± 0.23 x OD 25mm |
| 11. | ZD75P02100 | [2] | RING | KOBRing, Back-Up |
| 17. | ZD12P01500 | [1] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 18. | ZD85P01500 | [2] | RING | KOB |
