| . . | YN30V00101F1 | [1] | VALVE, CONTROL | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F2 | [1] | CONTROL VALVE | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F3 | [1] | CONTROL VALVE | KOBControl Valve Assembly Superseded by part number: YN30V00101F6 |
| 1. | NA | [1] | NOT SERVICED | FORBody |
| 3. | YN30V00001S154 | [3] | PLUG | KOB |
| 4. | YW30V00001S155 | [2] | PLUG | KOB |
| 8. | ZD12G03000 | [15] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 9. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 10. | ZD12P02400 | [19] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 11. | ZD12P01800 | [2] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 18. | YN30V00101S207 | [1] | GUARD | SM Superseded by part number: YN30V00101S094 |
| 25. | ZD12G04000 | [10] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 26. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOB |
| 30. | ZS23C08035 | [5] | SCREW,Hex Socket Head, M8 x 35mm | KOBM08x1.25x35mm |
| 60. | YN30V00101S517 | [1] | HYDRAULIC VALVE | SM |
| 61. | YN30V00101S518 | [1] | HYDRAULIC VALVE | SM |
| 66. | YN30V00101S527 | [1] | SPRING | SM |
| 67. | YN30V00101S528 | [1] | SPRING | SM |
| 78. | ZS23C14160 | [8] | SCREW,Hex Socket Head, M14 x 160mm | KOBM14x2.0x160mm |
| 79. | ZS23C14140 | [2] | SCREW,Hex Socket Head, M14 x 140mm | KOBM14x2.0x140mm |
| 82. | YN30V00120F2 | [2] | VALVE | KOBAssembly, Bypass (F2, F3 Only) |
| 83. | YN30V00101S010 | [1] | SPOOL | KOBSpool Assembly (F2 Only) Superseded by part number: YN30V00101R220 |
| K. | YN30V00101R100 | [1] | REPAIR KIT | KOBContains Items (31, 42, 43, 51, 52 & 53) (F1, F3 Only) Superseded by part number: YN30V00101R220 |
| K. | YN30V00116R110 | [1] | REPAIR KIT | SMContains Items (32, 42, 43, 51, 52 & 53) |
| K. | YN30V00101R120 | [1] | REPAIR KIT | KOBContains Items (33, 42, 43, 51, 52 & 53) |
| K. | YN30V00116R130 | [1] | REPAIR KIT | SMContains Items (34, 42, 43, 51, 52 & 53) |
| K. | YN30V00101R140 | [1] | REPAIR KIT | KOBContains Items (35, 46, 47, 51, 52 & 54) |
| K. | YN30V00101R150 | [1] | REPAIR KIT | KOBContains Items (36,44, 45, 51, 52 & 53) |
| K. | YN30V00101R170 | [1] | REPAIR KIT | KOBContains Items (37, 48, 50, 51, 52 & 53) |
| K. | YN30V00116R170 | [1] | REPAIR KIT | SMContains Items (38, 42, 49, 51, 52 & 55) |
| K. | YN30V00101R190 | [1] | REPAIR KIT | KOBContains Items (39, 48, 50, 51, 52 & 53) |
| K. | YN30V00101R200 | [1] | REPAIR KIT | KOBContains Items (40, 48, 50, 51, 52 & 53) |
| K. | YN30V00101R210 | [1] | REPAIR KIT | KOBContains Items (41, 44, 45, 51, 52 & 53) (F1, F2 Only) |
| K. | YN30V00101R220 | [1] | SPOOL | KOBKit, Repair, Contains Items (42, 43, 51, 52, 53 & 83) |
