| . . | YN30V00101F1 | [1] | VALVE, CONTROL | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F2 | [1] | CONTROL VALVE | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F3 | [1] | CONTROL VALVE | KOBControl Valve Assembly Superseded by part number: YN30V00101F6 |
| 3. | YN30V00001S154 | [3] | PLUG | KOB |
| 5. | NA | [1] | NOT SERVICED | FORPlug |
| 7. | ZD12P03800 | [7] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 8. | ZD12G03000 | [15] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 9. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 10. | ZD12P02400 | [19] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 12. | YN30V00101S201 | [5] | GUARD | SM |
| 13. | YN30V00101S202 | [4] | GUARD | SMCover |
| 16. | YN30V00001S205 | [7] | COVER | KOB |
| 24. | ZD12G05000 | [12] | O-RING,49.40mm ID x 55.60mm OD x 3.10mm | KOBID 49.40 ± 0.45 x OD 55mm |
| 25. | ZD12G04000 | [10] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 35. | YN30V00101S305 | [1] | SPOOL | SM Superseded by part number: YN30V00101R140 |
| 36. | YN30V00101S306 | [2] | REPAIR KIT | KOBSpool Superseded by part number: YN30V00101R150 |
| 37. | YN30V00101S307 | [1] | SPOOL | KOBSpool Superseded by part number: YN30V00101R170 |
| 39. | YN30V00101S309 | [1] | SPOOL | SM Superseded by part number: YN30V00101R190 |
| 40. | YN30V00101S310 | [1] | SPOOL | SM Superseded by part number: YN30V00101R200 |
| 44. | 2436U1165S371 | [3] | SPRING | KOB |
| 45. | 2436U1165S372 | [3] | SPRING | KOB |
| 46. | YN30V00079S323 | [1] | SPRING | KOB |
| 47. | YN30V00101S326 | [1] | SPRING | SM |
| 48. | YN30V00101S327 | [3] | SPRING | SM |
| 49. | YN30V00101S328 | [1] | SPRING | SM |
| 50. | YN30V00101S329 | [3] | SPRING | SM |
| 51. | 2436U1443S332 | [24] | SPRING SEAT | KOB |
| 52. | 2436U1165S336 | [12] | BOLT | KOB |
| 53. | 2436U1165S335 | [10] | STOP | KOB |
| 54. | YN30V00001S339 | [1] | STOP | KOB |
| 56. | YN30V00101S341 | [11] | HYDRAULIC VALVE | SM |
| 57. | YW30V00001S513 | [2] | POPPET | KOB |
| 62. | 2436U1165S521 | [11] | SPRING | KOB |
| 63. | YN30V00101S522 | [2] | SPRING | SM |
| 68. | YN30V00001S551 | [13] | PLUG | KOB |
| 69. | YW30V00001S556 | [2] | PLUG | KOB |
| 71. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 72. | YN22V00001F8 | [1] | HYDRAULIC VALVE | SMVALVE ASSY, MAIN RELIEF, Was YN22V00034F1 See Figure 8.044 (02) |
| K. | YN30V00101R100 | [1] | REPAIR KIT | KOBContains Items (31X1,42X1,43X1,51X2,52X1,53X1) (F1,F3 Only) Superseded by part number: YN30V00101R220 |
| K. | YN30V00116R110 | [1] | REPAIR KIT | SMContains Items (32X1,42X1,43X1,51X2,52X1,53X1) |
| K. | YN30V00101R120 | [1] | REPAIR KIT | KOBContains Items (33X1,42X1,43X1,51X2,52X1,53X1) |
| K. | YN30V00116R130 | [1] | REPAIR KIT | SMContains Items (34X1,42X1,43X1,51X2,52X1,53X1) |
| K. | YN30V00101R140 | [1] | REPAIR KIT | KOBContains Items (35X1,46X1,47X1,51X2,52X1,54X1) |
| K. | YN30V00101R150 | [1] | REPAIR KIT | KOBContains Items (36X1,44X1,45X1,51X2,52X1,53X1) |
| K. | YN30V00101R170 | [1] | REPAIR KIT | KOBContains Items (37X1,48X1,50X1,51X2,52X1,53X1) |
| K. | YN30V00116R170 | [1] | REPAIR KIT | SMContains Items (38X1,42X1,49X1,51X2,52X1,55X1) |
| K. | YN30V00101R190 | [1] | REPAIR KIT | KOBContains Items (39X1,48X1,50X1,51X2,52X1,53X1) |
| K. | YN30V00101R200 | [1] | REPAIR KIT | KOBContains Items (40X1,48X1,50X1,51X2,52X1,53X1) |
| K. | YN30V00101R210 | [1] | REPAIR KIT | KOBContains Items (41X1,44X1,45X1,51X2,52X1,53X1) (F1,F2 Only) |
| K. | YN30V00101R220 | [1] | SPOOL | KOBKit, Repair, Contains Items (42X1,43X1,51X2,52X1,53X1,83X1) |
