沃尔沃零件查询5.0GLPEFS; 5.0GiPEFS; 5.7GSPEFS; 5.7GSIPEFSElectrical SystemEngine HarnessEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3860040
|
[1] |
Wiring harness
|
|
| 2. |
3852527
|
[2] |
Terminal, engine ground
|
|
| 3. |
3852084
|
[1] |
Terminal, oil pressure switch
|
|
| 4. |
3853320
|
[1] |
Cap, oil pressure switch
|
|
| 5. |
3852233
|
[1] |
Terminal, oil pressure switch
|
|
| 6. |
3852235
|
[1] |
Terminal, alternator excite
|
|
| 7. |
3852245
|
[1] |
Terminal, alternator ground
|
|
| 8. |
3852233
|
[1] |
Terminal, alternator indicator light
|
|
| 9. |
3852233
|
[1] |
Terminal, ac tap
|
|
| 10. |
3852130
|
[2] |
Rubber cap
|
|
| 11. |
3852038
|
[1] |
Terminal, alternator output
|
|
| 12. |
3852235
|
[1] |
Terminal, alternator sense
|
|
| 13. |
3852084
|
[1] |
Terminal, water temperature switch
|
|
| 14. |
3853320
|
[1] |
Cap
|
|
| 15. |
3852233
|
[1] |
Terminal, starter solenoid ignition terminal
|
|
| 16. |
3852235
|
[1] |
Terminal, starter solenoid starter terminal
|
|
| 17. |
3852527
|
[1] |
Terminal, starter solenoid
|
|
| 18. |
3852527
|
[1] |
Terminal, starter solenoid
|
|
| 19. |
3854164
|
[1] |
Automatic fuse, 50 amp
|
|
| 20. |
3852001
|
[2] |
Tab washer, circuit breaker
|
|
| 21. |
3852064
|
[2] |
Nut, circuit breaker
|
|
| 22. |
3852245
|
[1] |
Terminal, circuit breaker to splice
|
|
| 23. |
3854192
|
[1] |
Relay, starter relay
|
|
| 24. |
3852254
|
[4] |
Terminal
|
|
| 25. |
3852227
|
[1] |
Terminal, electrical ground bracket
|
|
| 26. |
3852084
|
[1] |
Terminal, choke
|
|
| 27. |
3853320
|
[1] |
Cap, choke
|
|
| 28. |
3852229
|
[1] |
Terminal, receptacle
|
|
| 29. |
3852233
|
[1] |
Terminal, water temperature transmitter
|
|
| 30. |
3852210
|
[1] |
Bracket
|
|
| 31. |
3850403
|
[1] |
Relay
|
|
| 32. |
3852247
|
[1] |
Terminal
|
|
| 33. |
3852246
|
[3] |
Terminal
|
|
| 34. |
3853679
|
[2] |
Terminal
|
|
| 35. |
|
|
|
Not sold separately
|
| 36. |
|
|
|
Not sold separately
|
| 37. |
3852233
|
[1] |
Terminal, ignition coil
|
|
| 38. |
3852233
|
[1] |
Terminal, ignition coil distributor terminal
|
|
| 39. |
3852257
|
[1] |
Terminal, Plug
|
|
| 40. |
3853565
|
[1] |
Connector, trim sender
|
|
| 41. |
3852229
|
[1] |
Terminal, trim sender
|
|
| 42. |
979686
|
[1] |
Fuse, 40 amp
|
|
| 43. |
969197
|
[1] |
Fuse, 7.5 amp
|
|
| 44. |
3860455
|
[2] |
Fuse holder
|
|
