沃尔沃零件查询5.0GLPEFS; 5.0GiPEFS; 5.7GSPEFS; 5.7GSIPEFSElectrical SystemEngine Harness BracketEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
643 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3854164
|
[1] |
Automatic fuse, 50A
|
Main pump; trim pump
|
| 2. |
3852064
|
[2] |
Nut, circuit breaker terminals
|
|
| 3. |
3853620
|
[2] |
Hexagon screw, circuit breaker to bracket
|
|
| 4. |
3852001
|
[2] |
Tab washer, circuit breaker terminals
|
|
| 5. |
3854138
|
[1] |
Relay, starter motor
|
|
| 6. |
3850234
|
[1] |
Rubber cushion, relay mounting
|
|
| 7. |
3852118
|
[1] |
Nut, relay to isolator
|
|
| 8. |
3860368
|
[1] |
Bracket, circuit breaker & engine cable
|
|
| 9. |
3860369
|
[1] |
Cover, circuit breaker bracket
|
|
| 10. |
941263
|
[2] |
Grommet, circuit breaker bracket
|
|
| 11. |
3860524
|
[4] |
Retainer, circuit breaker cover to bracket
|
|
