| 1. | YN12B02175F1 | [1] | LINK | KOBAssembly, Bucket Superseded by part number: YN12B11101F1 |
| 1-1. | YN12B02176P1 | [1] | Link, Bucket | |
| 1-2. | YN12B02221P1 | [4] | BUSHING,80mm ID x 95mm OD x 47mm L | KOBID 80 x OD 95 x 47mm Long |
| 1-3. | LC12B01499P1 | [2] | BUSHING,80mm ID x 95mm OD x 89mm L | KOBID 80 x OD 95 x 89mm Long |
| 2. | YN12B01321P1 | [1] | LINK | KOB Superseded by part number: YN12B11270P1 |
| 3. | YN12B01322P1 | [1] | LINK | KOB |
| 4. | YN12B02215P1 | [2] | PIN,80mm OD x 561mm L | KOBReplaces YN12B02407P1 Superseded by part number: YN12B11170P1 |
| 5. | YN12B02216P1 | [1] | PIN | KOBPin -- Replaces YN12B02408P1 Superseded by part number: YN12B11271P1 |
| 6. | YN12B02217P1 | [1] | PIN,85mm OD x 478mm L | KOBPin -- Replaces YN12B02412P1 |
| 7. | HS18C16130G2 | [1] | BOLT,Hex, M16 x 130mm, Cl 10.9 | KOBM16x2.0x130mm |
| 8. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBM16x2.0x140mm |
| 9. | ZN18C16013 | [4] | NUT | KOBM16x2.0mm |
| 10. | 2445R220D4 | [6] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOBDust -- ID 80 X OD 95 x Th 5mm |
| 11. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 12. | ZG91S04000 | [1] | LUBE NIPPLE | KOB1/4" PT -- Straight |
| 13. | B16T0442D57 | [1] | SHIM,0.5mm Thk | KOB(M72 ID x 130 OD) |
| 14. | B16T0442D44 | [1] | SHIM,0.9mm Thk | KOB(M72 ID x 130 OD) |
| 15. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 16. | YN12B01122D1 | [2] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOBID 82 x OD 140 x Th 0.5mm |
| 17. | YN12B01122D2 | [2] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOBID 82 x OD 140 x Th 0.9mm |
| 18. | YN12B01122D3 | [2] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOBID 82 x OD 140 x Th 1.6mm |
| 19. | YN12B01601D1 | [4] | SHIM,82mm ID x 140mm OD x 2mm Thk | KOBID 82 x OD 140 x Th 2.0mm |
| 20. | YN12B01602D1 | [2] | SHIM,72mm ID x 130mm OD x 2mm Thk | KOBID 72 x OD 130 x Th 2.0mm |
