| A1. | ZX20H12115 | [1] | HOSE | KOB |
| A2. | YN42H02683D1 | [1] | HOSE | KOB |
| A3. | YN42H02628P1 | [1] | BAND | KOB |
| A4. | LC42H01750P1 | [1] | BAND | KOB Superseded by part number: LC42H02088P1 |
| A5. | YN43H01097P1 | [1] | CLAMP | KOBSingle -- 58x30x38mm (Ø28mm) |
| A6. | ZE13X20001 | [2] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| A7. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| A8. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A9. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| A10. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| A11. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| A12. | ZS28C14050 | [4] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOBSCREW M14x2.0x50mm |
| A13. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| A14. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| A15. | ZW16H12000 | [1] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| A16. | ZW16K14000 | [1] | WASHER | KOBID 15 x OD 24 x Th 2.5mm |
| A17. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A18. | ZW26K12000 | [1] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| A19. | ZW26K14000 | [4] | LOCK WASHER | KOBID 14 x OD 21.8 x Th 3.5mm |
| B1. | YN42H02377P1 | [1] | TUBE,27.2 mm OD x 1635.5, 62 mm Length | KOB |
| B2. | 2420R537D535 | [1] | HOSE,9.53mm ID x 5350mm L | SM |
| B3. | 2420R537D530 | [1] | HOSE,9.53mm ID x 5300mm L | KOB |
| B4. | LF42H01009P1 | [1] | BRACKET | KOB |
| B5. | YN28V00020F1 | [1] | HYDRAULIC VALVE | SMHolding -- See Figure 8.038 (00) Superseded by part number: 87353360 |
| B6. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of ZH22X06000), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| B7. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| B8. | HH35X06006G3 | [1] | ELBOW | KOB90° -- 3/8"PFx3/8"PFx42.5mm Long (Incls. O-Ring ZD12P01400) |
| B9. | ZE72X04000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of ZE72X04000), ID 10.80 ± 0.18 x OD 15mm, Not Shown |
| B10. | ZE13X16000 | [2] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| B11. | ZM73C10025 | [2] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| B13. | ZS28C12075 | [4] | SCREW,Hex Socket Head, M12 x 75mm | KOBScrew -- M12x1.75x75mm |
| B15. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| B17. | PY01P01043D3 | [17] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| B18. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring ZD12P01400) |
