纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (03-011[00]) - BOOM CYLINDER INSTALL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
433 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YN01V00151F2 | [2] | CYLINDER,Double Acting, 85mm Rod, 1355mm Stroke | KOBBoom |
| 1. | YN02B01721P1 | [1] | PIN,85mm OD x 776mm L | KOB |
| 2. | YN02B01720P1 | [2] | PIN,85mm OD x 258mm L | KOB |
| 3. | YN02B01108P1 | [2] | BOSS | KOB |
| 4. | HS18C16150G2 | [4] | SCREW | KOBM16x2.0x150mm |
| 5. | ZN18C16013 | [8] | NUT | KOBM16x2.0mm |
| 6. | YN02B01417D1 | [6] | SHIM,87mm ID x 140mm OD x 2mm Thk | KOBTh 2.0mm |
| 7. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOBTh 0.5mm |
| 8. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOBTh 0.9mm |
| 9. | B16T0442D62 | [1] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOBTh 1.6mm |
| 10. | YN02B01109D1 | [1] | SHIM,87mm ID x 120mm OD x 0.5mm Thk | KOBTh 0.5mm |
| 11. | YN02B01109D2 | [1] | SHIM,87mm ID x 120mm OD x 0.9mm Thk | KOBTh 0.9mm |
| 12. | YN02B01109D4 | [1] | SHIM,87mm ID x 120mm OD x 1.6mm Thk | KOBTh 1.6mm |
