| C1. | YN42H02618P1 | [1] | TUBE | KOBTube, Right -- U-Shape |
| C2. | YN42H02619P1 | [1] | TUBE,34.0 mm OD | KOBTube, Left -- U-Shape |
| C3. | HX20L04110DX | [1] | HOSE,6.3mm ID x 1100mm L | KOB |
| C4. | 2420R537D105 | [1] | HOSE,9.53mm ID x 1050mm L | KOB1050mm Long (41-21/64 in) |
| C5. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOB1100mm Long (43-19/64 in) Superseded by part number: HX21E06110DX |
| C6. | YN28V00023F1 | [2] | VALVE | KOBHolding |
| C7. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH22X06000), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| C8. | HG23F04004G1 | [2] | HYD CONNECTOR | KOB9/16"-18UNS - 1/4"PF x 33mm Long (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of HG23F04004G1), ID 10.8mm x OD 13.2mm, Not Shown |
| C9. | ZH32X06000 | [2] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| C10. | HH35X06006G3 | [2] | ELBOW | KOB90° -- 3/8"PFx3/8"PFx42.5mm Long (Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of HH35X06006G3), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| C11. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring 237-6006) Alternate O-Ring ZD12P01400 Superseded by part number: YT42H01128P1 |
| C12. | HH55Q06006G1 | [2] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| C13. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| C14. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| C15. | YY42H01330P1 | [2] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro | KOBID 7.65 ± 0.12 x OD 11.21mm |
| C17. | ZS28C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| C18. | ZS28C12075 | [8] | SCREW,Hex Socket Head, M12 x 75mm | KOBScrew -- M12x1.75x75mm |
| C19. | ZW26K12000 | [8] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| C20. | PY01P01043D6 | [10] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| C21. | PU13E01010D8 | [3] | RIGID TUBE | KOBID 15.2 x OD 19.5 x 850mm Long |
