纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (03-017[00]) - HYDRAULIC LINES, ARM CYLINDER LQ42H00136F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
199 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YN01V00175F1 | [1] | CYLINDER,Double Acting, 95mm Rod, 1558mm Stroke | KOBArm |
| A1. | ZX20H12115 | [1] | HOSE | KOB1150mm Long (45-17/64 in) |
| A2. | YN42H02683D1 | [1] | HOSE | KOB |
| A3. | YN42H02628P1 | [1] | BAND | KOB |
| A4. | LC42H01750P1 | [1] | BAND | KOB Superseded by part number: LC42H02088P1 |
| A5. | YN43H01097P1 | [1] | CLAMP | KOBSingle, 58x30x38mm (Ø28mm) |
| A6. | ZE13X20001 | [2] | CLAMP | KOBHalf Superseded by part number: ZE13X20000 |
| A7. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| A8. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT, Straight |
| A9. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| A10. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| A11. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| A12. | ZS28C14050 | [4] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOBM14x2.0x50mm |
| A13. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| A14. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| A15. | ZW16H12000 | [1] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| A17. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A19. | ZW26K14000 | [4] | LOCK WASHER | KOBID 14 x OD 21.8 x Th 3.5mm |
| B1. | LQ42H01520P1 | [1] | TUBE,1870.5, 86.7 mm L | KOB1870.5mm Long (73-41/64 in) |
| B3. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
