纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (03-022[02]) - ARM INSTAL (LONG REACH) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
880 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN12B01722P1 | [1] | PIN,90mm OD x 580mm L | KOBOD 90 x 542mm Long |
| 2. | YN12B01715P1 | [1] | PIN,85mm OD x 280mm L | KOBOD 85 x 280mm Long |
| 3. | HS18C16150G2 | [1] | SCREW | KOBM16x2.0x150mm |
| 4. | ZN18C16013 | [2] | NUT | KOBM16x2.0mm |
| 5. | 2420Z1047 | [1] | SLOTTED NUT | KOBM56x5.5mm Castle |
| 6. | ZP15D08100 | [1] | SPRING | KOBCotter -- OD 08 x 100mm Long |
| 7. | 2418Z715 | [1] | WASHER | KOBID 58 x OD 105 x Th 9.0mm |
| 8. | B16T0442D53 | [1] | SHIM,92mm ID x 160mm OD x 0.5mm Thk | KOBID 92 x OD 160 x Th 0.5mm |
| 9. | B16T0442D40 | [1] | SHIM,92mm ID x 160mm OD x 0.9mm Thk | KOBID 92 x OD 160 x Th 0.9mm |
| 10. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOBID 87 x OD 140 x Th 0.5mm |
| 11. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOBID 87 x OD 140 x Th 0.9mm |
| 12. | B16T0442D62 | [1] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOBID 87 x OD 140 x Th 1.6mm |
| 13. | YN02B01414D1 | [2] | SHIM,92mm ID x 160mm OD x 2mm Thk | KOBID 92 x OD 160 x Th 2.0mm |
| 14. | YN02B01415D1 | [2] | SHIM,87mm ID x 150mm OD x 2mm Thk | KOBID 87 x OD 150 x Th 2.0mm |
