纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (03-023[01]) - ARM 2.4M, 2.94M, 3.5M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
152 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN12B02175F1 | [1] | LINK | KOBLINK ASSY,BUCKET Superseded by part number: YN12B11101F1 |
| A1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONLINK,BUCKET |
| A1-2. | YN12B02221P1 | [4] | BUSHING,80mm ID x 95mm OD x 47mm L | KOB |
| A1-3. | LC12B01499P1 | [2] | BUSHING,80mm ID x 95mm OD x 89mm L | KOB |
| A2. | YN12B01227P1 | [1] | LINK | KOB Superseded by part number: YN12B11269P1 |
| A2. | YN12B01321P1 | [1] | LINK | KOBN&B Only Superseded by part number: YN12B11270P1 |
| A3. | YN12B01228P1 | [1] | LINK | KOB |
| A3. | YN12B01322P1 | [2] | LINK | KOBN&B Only |
| A4. | YN12B02217P1 | [1] | PIN,85mm OD x 478mm L | KOBBucket Link |
| A5. | YN12B11271P1 | [1] | PIN,75mm OD x 478mm L | KOBBucket Link |
| A6. | YN12B11443P1 | [2] | Tube | |
| A7. | YN12B02215P1 | [1] | PIN,80mm OD x 561mm L | KOBEnd of Arm Superseded by part number: YN12B11170P1 |
| A11. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A12. | ZG91S04000 | [1] | LUBE NIPPLE | KOB |
| B1. | YN12B00821F1 | [1] | ARM | KOB2.94M |
| B1. | YN12B00940F1 | [1] | ARM | KOB2.4M |
| B1. | YN12B00942F1 | [1] | ARM | KOB3.5M |
| B2. | 2445R220D4 | [2] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOBDust |
| B3. | 2445R220D3 | [2] | SEAL,70mm ID x 85mm OD x 5mm Thk | KOBDust |
| B4. | 2445R138D8 | [2] | SEAL,90mm ID x 105mm OD x 4mm Thk | KOBDust |
