纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (07-001[02]) - VALVE ASSY (SWING-REACTIONLESS) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
833 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 100. | LQ15V00001S100 | [1] | CASE | KOB |
| 151. | YW30V00001S157 | [2] | PLUG | KOB |
| 161. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 162. | ZD12P01200 | [2] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 163. | ZD12P00600 | [2] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 164. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 171. | ZS23C08055 | [4] | CAPSCREW,Hex Socket Head, M8 x 55mm | KOBSCREW M08x1.25x55mm |
| 400. | YN20V00004S400 | [2] | VALVE | KOB |
| 401. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 403. | ZD85P02000 | [2] | RING | KOBBack-Up -- ID 20 x OD 24 x Th 1.25mm |
