神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (00-001) - FILTER LIST Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
772 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME215002 | [1] | ENGINE OIL FILTER | KOB Superseded by part number: 84218257 |
| 2. | 2451R124-2A | [1] | ELEMENT | KOBFILTER, ENG FUEL |
| . . | VAME016823 | [1] | ELEMENT | KOB Superseded by part number: 2451R124-2A |
| 3. | YN57V00002S010 | [1] | ELEMENT | KOB Superseded by part number: 47640920 |
| 4. | YR50V00004P1 | [1] | HYDRAULIC OIL FILTER | KOB Superseded by part number: YR50V00004P1P |
| . . | YV50V00001P1 | [1] | ELEMENT | KOB |
| 5. | YN50V01001S005 | [1] | ELEMENT | KOB Superseded by part number: 84565888 |
| 5a. | YM50V01001S007 | [1] | O-RING | |
| 6. | YN50V01006P1 | [1] | ELEMENT | KOBFRESH AIR (not HEPA) Superseded by part number: YN50V01006P1P |
| 7. | YT20M00004S050 | [1] | ELEMENT | KOB(not HEPA) Superseded by part number: YT20M00004S050P |
| 8. | 2446R277S5 | [1] | AIR FILTER | KOB |
| 9. | 2446R277S6 | [1] | AIR FILTER | KOB |
| 10. | YN50V00002S001 | [1] | STRAINER ASSY. | KOB |
| 10a. | 45Z91D6 | [1] | O-RING | KOBID 97.79 ± 0.38 OD 108.45mm |
| 11. | VAME717651 | [1] | SPOOL | KOB |
| 12. | ZD11P14000 | [1] | O-RING | KOB |
| 13. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
