神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (00-002) - TUBE SLEEVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
967 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ZF93S06000 | [1] | FERRULE | KOB Superseded by part number: ZF96N06000, ZF96S06000 |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONTUBE SLEEVES, TYPE: NIPPON A.M.C., TUBE O.D. (0): 6 |
| . . | ZF93S08000 | [1] | FERRULE | KOB Superseded by part number: ZF96S08000, ZF96N08000 |
| . . | ZF93S10000 | [1] | FERRULE | KOB Superseded by part number: ZF96S10000, ZF96N10000 |
| . . | ZA93S10000 | [1] | TUBE NUT | KOB |
| . . | ZF93S12000 | [1] | FERRULE | KOB Superseded by part number: ZF96N12000, ZF96S12000 |
| . . | ZF93S15000 | [1] | FERRULE | KOB |
| . . | ZA93S15000 | [1] | FERRULE | KOB |
| . . | ZF93S18000 | [1] | FERRULE | KOB |
| . . | ZA93S18000 | [1] | FERRULE | KOB |
| . . | ZF93S22000 | [1] | FERRULE | KOB |
| . . | ZA93S22000 | [1] | RING | KOB |
| . . | ZF93S28000 | [1] | FERRULE | KOB Superseded by part number: ZA93S28000 |
| . . | ZA93S28000 | [1] | FERRULE | KOB |
| . . | ZF93S32000 | [1] | FERRULE | KOB |
| . . | ZF93S35000 | [1] | FERRULE | KOB |
| . . | ZA93S35000 | [1] | FERRULE | KOB |
| . . | ZF93S38000 | [1] | FERRULE | KOB |
