神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (00-004) - TUBE & HOSE PLUGS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
457 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ZF83P10000 | [1] | PLUG | KOB Superseded by part number: ZF96N10000, ZF86P10000 |
| . . | ZF93N10000 | [1] | NUT | KOB |
| . . | ZF83H10000 | [1] | PLUG | KOB |
| . . | ZF83P15000 | [1] | PLUG | KOB |
| . . | ZF93N15000 | [1] | NUT | KOB |
| . . | ZF83H15000 | [1] | PLUG | KOB |
| . . | ZF83P18000 | [1] | PLUG | KOB |
| . . | ZF93N18000 | [1] | NUT | KOB |
| . . | ZF83H18000 | [1] | PLUG | KOB |
| . . | 2444T1338D4 | [1] | PLUG | KOBTUBE & HOSE PLUGS, TYPE: "A" INTERNAL (For Hose End), TUBE DIA.: 22mm Superseded by part number: ZF86P22000, ZF96N22000 |
| . . | ZF93N22000 | [1] | NUT | KOB |
| . . | 2444T1329D4 | [1] | PLUG | KOB |
| . . | ZF83P28000 | [1] | PLUG | KOB Superseded by part number: ZA83P28000 |
| . . | ZF93N28000 | [1] | TUBE NUT | KOB Superseded by part number: ZA93N28000 |
| . . | 2444T1329D5 | [1] | PLUG | KOB Superseded by part number: ZF86P28000 |
| . . | ZF83P35000 | [1] | PLUG | KOB Superseded by part number: ZF96N35000, ZF86P35000 |
| . . | ZF93N35000 | [1] | NUT | KOB |
| . . | ZF83H35000 | [1] | PLUG | KOB |
