凯斯零件查询(LB334S) - BALER (9/12-) (60.220.170) - PICK-UP, MAIN TRANSMISSION, LH - C150 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84372941
|
[1] |
SPINDLE
|
ZED
|
| 2. |
86620027
|
[2] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 3. |
84240146
|
[1] |
BEARING,40mm ID x 80mm OD x 21mm W
|
PLO
|
| 4. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 5. |
100038
|
[8] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 6. |
9706687
|
[4] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
, Serial Range: -C098
|
| 6. |
300389
|
[4] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
, Start Serial: D099 Superseded by part number: 628-12035
|
| 7. |
378245
|
[2] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 8. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
