现代零件查询R320LC-7 PILOT HYD PIPING(BASE 2, S/MOTOR TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
677 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
PILOT HYD PIPING-BASE
|
|
| 2. |
31E3-0017
|
[1] |
FILTER-LINE
|
|
| 2-1. |
31E3-0044
|
[1] |
BODY
|
|
| 5. |
31EK-11130
|
[1] |
COUPLING-SCREW
|
|
| 7. |
31N6-22400
|
[1] |
ADAPTOR
|
|
| 8. |
X500-110001
|
[5] |
CONNECTOR-ORFS
|
|
| 11. |
X520-110001
|
[1] |
ELBOW-90,ORFS
|
|
| 15. |
X520-110012
|
[1] |
ELBOW-90,ORFS
|
|
| 16. |
X500-110012
|
[1] |
CONNECTOR-ORFS
|
|
| 17. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 20. |
X500-110003
|
[2] |
CONNECTOR-ORFS
|
|
| 21. |
X500-110004
|
[2] |
CONNECTOR-ORFS
|
|
| 23. |
31Q6-20210
|
[1] |
CONNECTOR-ORFS
|
|
| 25. |
X520-110003
|
[1] |
ELBOW-90,ORFS
|
|
| 26. |
X520-110004
|
[2] |
ELBOW-90,ORFS
|
|
| 30. |
X400-042007
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 36. |
S621-014001
|
[1] |
O-RING
|
|
| 43. |
P910-122012
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 44. |
P930-082016
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 47. |
P930-127018
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 49. |
P930-122017
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 50. |
P930-082023
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 52. |
X400-042011
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 53. |
X420-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 54. |
X420-042010
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 55. |
X420-042008
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 56. |
X420-042012
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 59. |
X400-042044
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 64. |
X500-110013
|
[1] |
CONNECTOR-ORFS
|
|
| 69. |
S621-011001
|
[4] |
O-RING
|
|
| A. |
S631-011004
|
[9] |
O-RING
|
|
| B. |
S631-014004
|
[3] |
O-RING
|
|
| C. |
S631-018004
|
[4] |
O-RING
|
|
| D. |
S631-024004
|
[4] |
O-RING
|
|
| F. |
S621-011001
|
[19] |
O-RING
|
|
| H. |
S621-014001
|
[6] |
O-RING
|
|
| I. |
S621-018001
|
[4] |
O-RING
|
|
| K. |
S631-008004
|
[1] |
O-RING
|
|
