现代零件查询R320LC-7 PILOT HYD PIPING(BASE 3, S/MOTOR TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
710 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
PILOT HYD PIPING-BASE
|
|
| 4. |
31E5-40500
|
[1] |
SWITCH-PRESSURE
|
|
| 6. |
31E5-11110
|
[1] |
ADAPTER
|
|
| 8. |
X500-110001
|
[4] |
CONNECTOR-ORFS
|
|
| 11. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 13. |
31N6-25110
|
[1] |
ELBOW-90,LONG
|
|
| 19. |
31N4-22150
|
[1] |
TEE-LONG,ORFS
|
|
| 23. |
31Q6-20210
|
[1] |
CONNECTOR-ORFS
|
|
| 27. |
X820-065152
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 31. |
X420-042007
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 32. |
P930-062015
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 34. |
31N8-40100
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 35. |
X840-515151
|
[1] |
TEE-RUN TYPE
|
|
| 38. |
S551-050203
|
[30] |
CLAMP-BAND
|
|
| 42. |
S035-082526
|
[2] |
BOLT-W/WASHER
|
|
| 54. |
X420-042010
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 55. |
X420-042008
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 56. |
X420-042012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 60. |
X420-042048
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 61. |
X420-042051
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 62. |
P930-043056
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 64. |
X500-110013
|
[2] |
CONNECTOR-ORFS
|
|
| 69. |
S621-011001
|
[2] |
O-RING
|
|
| 70. |
S621-012001
|
[1] |
O-RING
|
|
| A. |
S631-011004
|
[10] |
O-RING
|
|
| B. |
S631-014004
|
[3] |
O-RING
|
|
| F. |
S621-011001
|
[14] |
O-RING
|
|
| G. |
S621-012001
|
[1] |
O-RING
|
|
| K. |
S631-008004
|
[1] |
O-RING
|
|
