纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (08-004[03]) - CRANKCASE COVERS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
479 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 2. | 4899109 | [2] | SCREW,Hex, M10 x 1.5 x 80 | BASM10x1.5x80mm |
| 2. | 4892915 | [11] | FLANGE BOLT,Hex, M10 x 1.5 x 40mm | TORM10x1.5x40mm |
| 2. | 4899076 | [5] | SCREW,Hex Flg, M12 x 1.75 x 80 | TORM12x1.75x80mm |
| 2. | 4899074 | [3] | SCREW,Hex Flg, M12 x 1.75 x 120 | TORM12x1.75x120mm |
| 3. | 4895155 | [1] | COVER | TOR |
| 4. | 4895378 | [1] | BUTTON PLUG,M29.2 | TORØ29x32mm |
| 5. | 4895379 | [1] | O-RING,21.82mm ID x 3.53mm Width | TORID 21.82 x OD 28.88 x Th 3.53mm Superseded by part number: 17288480 |
| 6. | 2854073 | [1] | COVER | TORFLANGE (Includes Ref 11) |
| 7. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TORM8x1.25x20mm Superseded by part number: 16673635 |
| 8. | 4890833 | [1] | OIL SEAL,M130 x 155 x 12.5/16 | TOR Superseded by part number: |
| 9. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BASM08x1.25x16mm |
| 10. | 2854916 | [1] | HOUSING | TORREAR - FLYWHEEL HOUSING |
| 11. | 2854075 | [1] | O-RING,0.103" Thk x 2.987" ID, -151 | TOR |
