神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (02-007) - ROLLER ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
612 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N10084F1 | [1] | ROLLER | KOB |
| 1. | C0106000N01 | [1] | ROLLER | |
| 2. | C0105000N02 | [1] | SHAFT | |
| 3. | C0105000N32 | [2] | BEARING, CONIC ROLLER | |
| 4. | C0104000N14 | [1] | DISK, INTERNAL FACE | |
| 5. | C0104200N03 | [2] | PIN | |
| 6. | C0105000N12 | [3] | BOLT | |
| 7. | C0106000N10 | [1] | O-RING | |
| 8. | A0106100N01 | [2] | RING, SEAL | |
| 9. | A0106100N02 | [2] | O-RING | |
| 10. | C0105200N01 | [1] | COLLAR | |
| 11. | C0104000N06 | [1] | RING, ELASTIC | |
| 12. | C0106000N05 | [1] | O-RING | |
| 13. | C0104000N27 | [1] | PLATE, SECURITY | |
| 14. | A0104200N05 | [3] | WASHER ELASTIC | |
| 15. | A0104200N08 | [1] | O-RING | |
| 16. | A0104200N03 | [1] | PLUG,(3/4" X 16) | |
| 17. | C0105000N13 | [2] | BOLT | |
| 16. | C0105000Y03 | [1] | COVER | |
