神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (02-011) - DOZER INSTALLATION, C-FRAME Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
228 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J21252F1 | [1] | GLOW PLUG | GLOW PLUG |
| 1. | 2412J1617 | [1] | C-FRAME | |
| 2. | 2425R433 | [2] | BEARING CAP | |
| 3. | 2420T9271 | [6] | SUM | |
| 4. | 2414P11017 | [1] | GUARD | KOB(Attach using Ref # 9 - 11) Superseded by part number: AW709-213-014 |
| 5. | 2414P11018 | [1] | GUARD | KOB(Attach using Ref # 9 - 11) |
| 6. | 2420T9273 | [4] | BOLT 3/8X2-1/4 NC | BOLT 3/8X2-1/4 NC |
| 7. | 2420T9277 | [4] | BOLT | |
| 8. | 2405P797 | [2] | BUSHING | BUSHING |
| 9. | 2445Z1612 | [4] | SEAL | |
| 10. | 2420T9279 | [2] | NUT 3/4\"-10 UNC | NUT 3/4"-10 UNC |
| 11. | 2420T9302 | [8] | BOLT | KOB |
| 12. | 2432T6958 | [4] | CLAMP | |
