神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (01-004) - ENGINE INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
452 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM02P00002F1 | [1] | ENGINE INSTAL | |
| 1. | YM02P01009P1 | [1] | BRACKET | KOB |
| 2. | YM02P01013P1 | [1] | BRACKET | KOB Superseded by part number: YM02P01040P1 |
| 3. | YM02P01011P1 | [1] | BRACKET | KOB |
| 4. | YM02P01012P1 | [1] | BRACKET | |
| 5. | YW02P01002P1 | [2] | RUBBER | KOB Superseded by part number: YW02P01002P2 |
| 6. | YW02P01003P1 | [2] | ENGINE MOUNT | KOB Superseded by part number: YW02P01003P2 |
| 7. | YW02P01004P1 | [4] | ENGINE MOUNT | KOB |
| 8. | ZS18C18100 | [4] | CAP,Hex, M18 x 100mm | KOBScrew -- M18x2.50x100mm |
| 9. | ZS18C10025 | [8] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 10. | ZS18C10030 | [8] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 11. | ZN18C18015 | [4] | NUT | KOBM18x2.5mm |
| 12. | ZW16H18000 | [4] | WASHER | KOBID 19 x OD 36 x Th 4.5mm |
| 13. | ZW16H10000 | [16] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 14. | YT52S00001P1 | [1] | SENSOR,50 Degrees C to 120 Degrees C | KOBCoolant Temperature (Thermo) Superseded by part number: YN52S00077F1 |
| 15. | YW02P01005D1 | [1] | SHIM | KOB(1.0) |
| 16. | YW02P01005D2 | [1] | SHIM | KOB(0.6) |
