神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (01-003) - ENGINE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
722 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM02P00001F1 | [1] | ENGINE | KOB |
| 2. | YT52S00001P1 | [1] | SENSOR,50 Degrees C to 120 Degrees C | KOBCoolant Temperature (Thermo) Superseded by part number: YN52S00077F1 |
| 3. | YM05P01004P1 | [1] | HOSE | KOBUpper |
| 4. | YM05P01003P1 | [1] | HOSE | KOBLower |
| 5. | YM20M01282D1 | [1] | V-BELT | KOBA/C COMPRESSOR Superseded by part number: 84214731 |
| 6. | VAME077148 | [1] | RELAY | KOB |
| 7. | VAME072890 | [1] | HEATER | KOB Superseded by part number: VA3439000602 |
| 8. | VAMH014093 | [1] | V-BELT | KOB(2-Belt Set) (L=1165MM) |
| 9. | VAMC840219 | [1] | SWITCH | KOB Superseded by part number: H411892 |
| 10. | VAMC849577 | [1] | SENSOR | KOB |
| 11. | VAMC867765 | [1] | SENSOR | KOB |
| 12. | VAMD050079 | [1] | GASKET | KOB |
| 13. | VAME016823 | [1] | ELEMENT | KOB Superseded by part number: 2451R124-2A |
| 14. | VAME215002 | [1] | ENGINE OIL FILTER | KOB Superseded by part number: 84218257 |
| 15. | VAME017614 | [1] | ALTERNATOR | KOB |
| 16. | VAMED49303 | [1] | STARTER ASSY (5.0KW), MITSUBISHI COMPONENTS | |
| 17. | VAME995106 | [1] | THERMOSTAT | KOB |
| 18. | VAME039860 | [1] | SWITCH,105.5 Degrees C | KOB |
| 19. | VAME217057 | [1] | HOSE | KOB |
| 20. | VAME217160 | [1] | FAN | KOB |
