纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (05-002[00]) - DIA KITS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN32TU1063F1 | [1] | KIT | KOB2 WAY - Foot Control (No Boom or Arm Piping) |
| 2. | YN32TU1063F2 | [1] | KIT | KOB2 WAY - Hand Control (No Boom or Arm Piping) |
| 4. | YN32TU1063F4 | [1] | KIT | KOBBoom 2 Way / 1 Way Piping ONLY |
| 6. | YN32TU1063F6 | [1] | KIT | KOBBoom 2 Way with Rotation Piping ONLY |
| 7. | YN32TU1063F7 | [1] | KIT | KOBSTD Arm 2 Way / 1 Way Piping ONLY |
| 9. | YN32TU1063F9 | [1] | KIT | KOBSTD Arm 2-way with Rotation Piping ONLY |
| 10. | YN32TU1063FA | [1] | Long Arm 2-way Piping ONLY | |
| 11. | YN32TU1063FB | [1] | KIT | KOBPattern Changer |
| 23. | YN32TU1063FC | [1] | Undercovers | |
| 12. | YN32TU1063FD | [1] | KIT | KOBRotation + 2WAY - Hand Control (No Boom or Arm Piping) |
| 14. | YN32TU1063FF | [1] | Long Arm Rotation + 2Way Piping ONLY | |
| 15. | YN32TU1063FG | [1] | Short Arm 2-way Piping ONLY | |
| 16. | YN32TU1063FH | [1] | Short Arm Rotation Piping ONLY | |
| 17. | YN32TU1063FJ | [1] | Short Arm Rotation + 2Way Piping ONLY | |
| 18. | YN32TU1063FK | [1] | Extreme Reach Boom Rotation | |
| 19. | YN32TU1063FL | [1] | Extreme Reach Arm Rotation | |
| 20. | YN55C00013F1 | [1] | SUN VISOR | SMRain Visor Front |
| 21. | YN25C00008F1 | [1] | GUARD ASSY. | KOBVandalism Guard (with TOP opening tool box) |
| 22. | YM25C00001F1 | [1] | GUARD ASSY. | KOBVandalism Guard (With SIDE opening tool box) |
| 24. | YN21PU0003F1 | [1] | DIA KIT, ADDITIONAL PRODUCTS | KOBFuel Stop Valve |
| 25. | LS32TU1044F1 | [1] | Cab Install | |
