纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (05-003[00]) - FLASHER UNIT - ALARM TRAVEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
336 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM80S00001F1 | [1] | LAMP | KOBLeft Lamp Assy, See Figure 05-003(02) |
| 2. | YM80S00001F2 | [1] | LAMP | KOBRight Lamp Assy, See Figure 05-003(02) |
| 3. | 71452049 | [2] | ELECTRIC INSULATION | SM(2420R372D19) |
| 4. | 2420Z1322 | [1] | GROMMET | KOB(YN24S00010P1) |
| 5. | 72951499 | [12] | CLIP | IMO(PY01P01043D3) Superseded by part number: PY01P01043D8 |
| 6. | 87526680 | [8] | RETAINER COLLAR | SM(YN13E01375P1) Superseded by part number: YN13E01375P1 |
| 7. | LC53E01004P1 | [1] | WIRE HARNESS | KOB |
| 8. | YN53S00003F1 | [1] | ALARM | KOB |
| 9. | 16043434 | [2] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | LEC(ZS18C08020) Superseded by part number: 16043431 |
| 10. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC(ZW16P08000) Superseded by part number: 86624184 |
| 11. | YN13E01630P1 | [1] | HARNESS | KOBHarness to Flasher Assemblies |
