神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (01-017) - VALVE INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
450 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00001F1 | [1] | VALVE ASSY, CONTROL | VALVE ASSY, CONTROL |
| . . | YM30V00005F1 | [1] | CONTROL VALVE | KOBVALVE ASSY, CONTROL (NBBLER & BREAKER), SeeCPM |
| . . | YM64H00001F1 | [1] | VALVE INSTAL | |
| 1. | YM64H01007P1 | [1] | BRACKET | |
| 2. | YM64H01005P1 | [1] | BRACKET | |
| 3. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 4. | ZS18C12060 | [3] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 5. | ZW16H12000 | [10] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 6. | ZN18C12010 | [3] | NUT | KOBM12x1.75mm |
| 7. | PV02B01073D1 | [2] | CAP | KOB08.4mm Plastic |
