| . . | YM30VU0005F1 | [1] | X | KOB |
| . . | YM64HU0001F1 | [1] | VALVE INSTAL, DOZER, -2/14/2001 | |
| . . | YM64HU0001F2 | [1] | VALVE INSTAL, DOZER, 2/14/2001- | |
| 1. | YM64HU1001P1 | [4] | CONNECTOR(PF3/4-ORS 1/2) | |
| 2. | ZH32X12016 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 1", O-Ring | KOB |
| 3. | ZG33F12012 | [1] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB90° -- 1-3/16" -12UN x 3/4" PF (Incls. O-Ring ZD12P02400) |
| 4. | ZS13C12045 | [3] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 5. | ZW23X12000 | [4] | WASHER | KOBWASHER, LOCK (M12) |
| 6. | ZW13H12000 | [4] | WASHER | KOB |
| 7. | YM64HU1002P1 | [2] | CONNECTOR (PF 3/4 - ORS 3/8) | |
| 8. | YM19HU1003P1 | [2] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOBID 09.25 ± 0.13 x OD 12.81mm Superseded by part number: 9993141 |
| 9. | YM19HU1003P1 | [4] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOBID 09.25 ± 0.13 x OD 12.81mm Superseded by part number: 9993141 |
| 10. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 11. | YM19HU1003P1 | [2] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOBID 09.25 ± 0.13 x OD 12.81mm, (F2 only) Superseded by part number: 9993141 |
| 12. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 13. | ZN13C12010 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 14. | YM64HU1001D1 | [1] | STUD, BOLT | |
