神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (01-020) - HYD LINES, UPP (PUMP) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
721 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30HU0001F1 | [1] | HYD LINES, UPPER (PUMP) | |
| 1. | YM06H01002D1 | [1] | HOSE 800mm Long (31-1/2 in) | HOSE 800mm Long (31-1/2 in) |
| 2. | 2444Z4504 | [1] | ELBOW | |
| 3. | ZE12X20000 | [2] | CLAMP | KOB |
| 4. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 5. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 6. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 7. | YM03HU1012D1 | [1] | HOSE | HOSE |
| 8. | ZE12X16000 | [2] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 9. | ZS18C10040 | [4] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| 10. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 11. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 12. | YM30HU1007P1 | [1] | TUBE | KOB |
| 13. | YN43H01097P1 | [2] | CLAMP | KOBSingle -- 58x30x38mm (Ø28mm) |
| 14. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| 15. | YM30HU1010P1 | [1] | SUPPORT | |
| 16. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 17. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 18. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 19. | ZD12A02100 | [1] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 20. | ZW26X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
