纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-005[01]) - ENGINE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
926 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN02P01099P1 | [1] | BRACKET | KOB |
| 2. | YN02P01098P1 | [1] | BRACKET | KOB |
| 3. | YN02P01111P1 | [1] | BRACKET | KOB |
| 4. | YN02P01040P1 | [1] | BRACKET | KOB |
| 5. | YN02P01024P2 | [4] | COVER | KOB |
| 6. | YN02P01022P1 | [4] | RUBBER MOUNTING | KOB(BLUE) |
| 7. | YN02P01023P1 | [4] | RUBBER MOUNTING | KOB(BLACK) Superseded by part number: LC02P01033P1 |
| 8. | YN02P01106P1 | [4] | PLATE | KOB |
| 9. | ZS18C18140 | [4] | SCREW,Hex, M18 x 140mm | KOBM18x2.50x140mm |
| 10. | ZN18C18015 | [4] | NUT | KOBM18x2.5mm |
| 11. | ZW16H18000 | [8] | WASHER | KOBID 19 x OD 36 x Th 4.5mm |
| 12. | ZM73C12035 | [10] | BOLT,M12x35mm - Course Thread | KOBM12x1.75x35mm (Incls. Washer) |
| 13. | ZM73C12045 | [4] | BOLT,M12x45mm - Course Thread | KOBM12x1.75x45mm (Incls. Washer) |
| 21. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| 26. | YN02P01032P1 | [1] | HYD CONNECTOR | KOB1/2" NPTF - M14x1.50 x 34.5mm Long |
| 27. | YN50S00045P1 | [1] | THERMOSTATIC SWITCH | KOBSWITCH, THERMO |
| 28. | YN75S00007P1 | [1] | FAN,7 Blades, 550mm OD | SM |
| 29. | YN50S00017P1 | [1] | PRESSURE SWITCH | KOBOil Pressure Switch Superseded by part number: 504085003 |
| 38. | YN02P01149P1 | [2] | SEAL | KOB |
| 39. | YN50S00048P1 | [1] | THERMOSTATIC SWITCH,On, 10° C, 50° F; Off, -12° C, 10.4° F | KOB(Used for Engine Temp Sensor) Superseded by part number: 87568522 |
| 40. | YN02P01155P1 | [1] | ADAPTER | KOBM18x1.50 - M14x1.50 x 34mm Long (Incls. O-Ring 637-63153) Superseded by part number: 71450201 |
