纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-005[02]) - ENGINE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
447 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 14. | LC02P01036D8 | [1] | HOSE,19.05mm ID x 1600mm L | KOB1550mm Long (61 in) |
| 15. | LC02P01036D9 | [1] | HOSE,19.05mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 16. | YN02P01164P1 | [1] | HYD CONNECTOR | KOB3/4"PFx1-1/16-12UNx50mm Long (Incls. O-Ring YN02P01163P1) |
| 17. | YN02P01165P1 | [3] | HYD CONNECTOR | SMElbow, 90° -- 3/4"PFx1-1/16-12UN (Incls. O-Ring YN02P01163P1) |
| 18. | YN02P01137P1 | [1] | BRACKET | KOB |
| 19. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 20. | ZM73C10030 | [2] | BOLT,M10x30mm - Course Thread | KOBM10x1.50x30mm (Incls. Washer) |
| 22. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 23. | ZM22C10065 | [1] | BOLT | KOBM10x1.50x65mm (Incls. Washer & Lockwasher) |
| 24. | YT03H01019P1 | [2] | BUSHING | KOB Superseded by part number: YN03H01075P1 |
| 25. | YT30H01012P1 | [1] | GROMMET | KOB |
| 31. | YM02P01028P1 | [1] | CLAMP | KOBDouble Line -- 145.5x38x36mm |
| 32. | YM02P01029P1 | [1] | PLATE | KOB |
| 33. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOBWire Ties -- 292mm Long |
