纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-012[02]) - FUEL LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
301 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | LQ21PU1003P1 | [1] | HYD CONNECTOR | KOB |
| 6. | YN21P01046P1 | [1] | FUEL HOSE,6mm ID x 2900mm L | KOB(Injection Pump to Fuel Tank) |
| 8. | YN21P01048P1 | [1] | BRACKET | KOB |
| 9. | LQ21P01005P1 | [5] | COUPLING,M14 x 1.5 x 12mm ID x 7mm ID | KOB |
| 10. | YY21P01002P1 | [5] | PACKING | KOB Superseded by part number: VIG0293414080 |
| 12. | ZM73C12025 | [1] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 13. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 14. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 15. | ZC46X25011 | [1] | CLIP | KOB |
| 22. | YN21P01124P1 | [1] | HOSE,10mm ID x 2500mm L | KOB(Fuel Tank to Stop Valve) |
| 26. | YN21P01078P1 | [1] | PACKING | KOB |
