纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-012[01]) - FUEL LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
300 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87646724 | [2] | FUEL FILTER | KOB Superseded by part number: 84565884 |
| 2. | YN21P01055F1 | [1] | FILTER ASSY | KOBFilter Assembly, Fuel (Incls. Filter Element & Sensor) |
| 4. | YN21P01044P1 | [2] | FUEL HOSE,6mm ID x 2200mm L | KOB(Feed Pump tp Main Filter) |
| 5. | YN21P01045P1 | [1] | FUEL HOSE,6mm ID x 2100mm L | KOB(Main Filter to Injection Pump) |
| 6. | YN21P01046P1 | [1] | FUEL HOSE,6mm ID x 2900mm L | KOB(Injection Pump to Fuel Tank) |
| 9. | LB21P01005P1 | [5] | FITTING,M14 x 1.5 x 16mm ID x 7.90mm ID | KOB Superseded by part number: 8602542 |
| 10. | YY21P01002P1 | [5] | PACKING | KOB Superseded by part number: VIG0293414080 |
| 11. | ZM73C10030 | [4] | BOLT,M10x30mm - Course Thread | KOBM10x1.50x30mm (Incls. Washer) |
| 13. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 14. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 16. | ZC48X12011 | [1] | CLAMP | KOB |
| 17. | YN13E01375P1 | [2] | CLIP,M8 x 8.20mm Shank | KOB |
| 18. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOB |
| 19. | YN21P01060P1 | [1] | PLUG | KOB |
| 20. | YN25V00006P1 | [1] | SHUT-OFF VALVE | KOB |
| 21. | YN21P01062P1 | [2] | HYD CONNECTOR | KOB |
| 22. | YN21P01124P1 | [1] | HOSE,10mm ID x 2500mm L | KOB(Fuel Tank to Stop Valve) |
| 24. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 25. | ZC46X22011 | [2] | CLIP | KOB |
| . . | YN21P01149P1 | [1] | FUEL HOSE,7.50mm ID x 2400mm L | KOBNot Illustrated (Water Separator to Feed Pump) |
