纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-013[00]) - FUEL TANK INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
611 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| A2. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| A3. | LE33H01017D1 | [3] | SHIM | KOB(1.0) |
| A4. | YN52S00045F1 | [1] | SENSOR | SMFuel Level |
| . . | YN52S00045S005 | [1] | GASKET | KOBPart Of Sensor, Not Shown |
| A6. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBM05x0.8x12mm |
| A7. | ZW26X05000 | [5] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| A8. | YN25V00001P1 | [1] | VALVE | KOBFuel Shut Off (Manual) |
| B2. | YN20P01034P2 | [1] | CAP | KOBFuel Tank Filler |
| B3. | YN50V00021P1 | [1] | FILTER STRAINER | KOB Superseded by part number: YN50V00029P1 |
| B4. | YN20P01290P1 | [1] | FLANGE | KOBFlange |
| B5. | ZM73C10020 | [6] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| B6. | ZD11G16000 | [1] | O-RING,5.7mm Thk x 159.3mm ID, 70 Duro | KOBID 159.3 ± 1.26 x OD 161.82mm |
