纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-014[00]) - HYDRAULIC TANK ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
462 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| A2. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| A3. | LE33H01017D1 | [3] | SHIM | KOB(1.0) |
| B2. | YN50V00025F1 | [1] | STRAINER ELEMENT | KOBIncls. Refs. B2-1 - B2-5 |
| B2-1. | YN50V00002S001 | [1] | STRAINER ASSY. | KOB |
| B2-3. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| B2-4. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| B2-5. | LS50V00007S003 | [1] | BOLT | KOBM10x1.50x585mm |
| .. | 2446R110S6 | [1] | SPRING | KOBNot Shown |
| .. | 2446R110S2 | [1] | HOLDER | KOBNot Shown |
| B3. | YN57V00005F1 | [1] | BREATHER | KOBAssembly, Incls. Refs. B3-1 - B3-8 Superseded by part number: YN57V00010F1 |
| B3-1. | NA | [1] | NOT SERVICED | FORBody |
| B3-2. | YN57V00005S002 | [1] | ELEMENT | KOBFilter Superseded by part number: YN57V00010S002 |
| B3-4. | YN57V00004S004 | [1] | SEAL | KOB |
| B3-6. | 2446U260S10 | [1] | NUT | KOBM12x1.25mm |
| B3-8. | 2446U260S8 | [1] | PACKING | KOB |
| B4. | ZS28C06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm |
| B5. | ZW26K06000 | [4] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| B6-2. | YN52V01008S002 | [1] | PLATE | KOB |
| B6-3. | YN21V00015P1 | [1] | CHECK VALVE | KOB |
| B6-4. | ZD11G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOBID 89.40 ± 0.77 x OD 95mm |
| B6-5. | YN52V01008S005 | [1] | PACKING | KOB |
| B6-6. | LC33H01009P1 | [1] | SPRING | KOB |
| B6-7. | YN52V01011P2 | [2] | ELEMENT | KOBFilter Superseded by part number: YN52V01020P1 |
| .. | YN33H00081F1 | [1] | TANK | KOBAssembly |
| C1. | YN33H00083P1 | [1] | TANK | KOB |
| C2. | YN33H01283P1 | [1] | COVER | KOB |
| C3. | YN33H01259P1 | [1] | COVER | KOB Superseded by part number: YN33H01259P2 |
| C4. | ZD11G19000 | [2] | O-RING,189.30mm ID x 200.70mm OD x 5.70mm | KOBID 189.30 ± 1.47 x OD 200mm |
| C5. | ZM73C10025 | [12] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| C6. | YN58S00009F1 | [1] | GAUGE | KOBIncls. Refs. C6-1 - C6-6 |
| C7. | ZE72X08000 | [1] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| .. | ZD12P01800 | [1] | O-RING | KOB(Part of ZE72X08000), ID 17.8mm x OD 20.2mm, Not Shown |
| K. | YN52V01008R600 | [1] | ELEMENT | KOBKIT Contains Items (B6-4)X1, (B6-5)X1,(B6-7)X2, (C4)X1 Superseded by part number: YN52V01016R600 |
