纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-020[01]) - HYD LINES, PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
346 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN30H01199D1 | [1] | HOSE | KOB1230mm Long (48-27/64 in) |
| A2. | YN30H01200D1 | [1] | HOSE | KOB1200mm Long (47-1/4in) |
| A10. | ZE13X16000 | [8] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| A13. | HM83C12040G1 | [16] | BOLT | KOBM12x40mm |
| A17. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
