| A1. | YN35V00047F1 | [1] | HYDRAULIC VALVE | SMASSY, SOLENOID See Fig. 07-010(00) Superseded by part number: YN35V00047F3 |
| A3. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| A4. | 2420R349D055 | [1] | HOSE,6.35mm ID x 550mm L | KOB550mm Long (21-21/32 in) |
| A5. | 2420R349D115 | [2] | HOSE,1150.00 mm | KOB Superseded by part number: HX21E04115DX |
| A6. | 2420R349D185 | [1] | HOSE,6.35mm ID x 1850mm L | KOB |
| A7. | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| A8. | 2420R537D082 | [1] | FLEXIBLE HOSE,9.60mm ID x 820mm L | SM820mm Long (32-9/32 in) Superseded by part number: 2420R537D085 |
| A9. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB1400mm Long (55-7/64 in) |
| A10. | 2420R537D145 | [1] | HOSE,9.53mm ID x 1450mm L | KOB |
| A11. | 2420R537D270 | [1] | FLEXIBLE HOSE,9.60mm ID x 2700mm L | KOB2700mm Long (106-19/64 in) |
| A12. | 2420R537D300 | [1] | HOSE,9.60mm ID x 3000mm L | KOB Superseded by part number: HX21E06300DX |
| A13. | 2420R537D280 | [1] | HOSE,9.60mm ID x 2800mm L | KOB Superseded by part number: HX21E06280DX |
| A14. | ZH22X04000 | [5] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| A15. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| A16. | ZH32X04000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| A17. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| A18. | 2444Z2336 | [1] | HYD CONNECTOR | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| A19. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| A20. | HH35X06006G3 | [1] | ELBOW | KOB90° -- 3/8"PFx3/8"PFx42.5mm Long (Incls. O-Ring ZD12P01400) |
| A24. | ZM73C10025 | [1] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| A25. | ZS18C10090 | [1] | SCREW,Hex, M10 x 90mm | KOBM10x1.50x90mm |
| A26. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| A30. | 2444Z2891 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| A31. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| A32. | HH45X06006G2 | [1] | HYD CONNECTOR | SMElbow, 45° -- (Incls. O-Ring ZD12P01400) |
| . . | PU13E01010DK | [1] | TUBE | KOBNot Shown |
| . . | PY01P01043D6 | [1] | CABLE TIE,4.80mm W x 383mm L | KOBNot Shown |
