纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-033[00]) - CONTROL LINES, VALVE (SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
295 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZX23M06320 | [1] | HOSE ASSY. | KOB |
| 2. | ZX23M06290 | [1] | HOSE,9.53mm ID x 2900mm L | SM2900mm Long (114-11/64 in) |
| 3. | 2444R941D10 | [2] | FLEXIBLE HOSE | KOB1700 mm long (66-59/64 in) |
| 4. | 2444T2580 | [2] | TEE | KOB3/8" PF x 61mm Long (No O-Ring supplied) |
| 5. | 2444Z2359 | [1] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| 6. | PY01P01043D6 | [14] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 7. | 2418Z1333D4 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 500mm Length | KOB |
