纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-035[00]) - CONTROL LINES, REMOTE (NIBBLER & BREAKER - FOOT) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
450 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN30V00080F1 | [1] | VALVE | KOBPILOT (See Fig. 07-006[00]) |
| 2. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 3. | 2420R349D165 | [1] | HOSE,1650.00 mm | KOB Superseded by part number: HX21E04165DX |
| 4. | 2420R349D370 | [1] | HOSE,3700.00 mm | KOB Superseded by part number: HX21E04370DX |
| 5. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 6. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 7. | ZH32X04000 | [2] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 8. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 9. | LC52S00019P1 | [1] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100) |
| 10. | HM83C10030G1 | [2] | BOLT | KOBM10x30mm |
| 11. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
