| 1. | ZX22M12048 | [1] | HOSE | KOB480mm Long (18-57/64 in) |
| 2. | 2420R537D052 | [1] | HOSE,9.60mm ID x 520mm L | KOB520mm Long (20-15/32 in) Superseded by part number: 2420R537D055 |
| 3. | 2420R537D050 | [1] | HOSE,9.53mm ID x 500mm L | KOB |
| 4. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 5. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMInline |
| 6. | YN06H01044P1 | [1] | TEE | KOB(2) 1/4" PF x (2) 3/8" PF x 61mm Long (Incls. O-Rings ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of HH25R04004G5), ID 10.8mm x OD 13.2mm, Not Shown |
| 7. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 8. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| . . | 237-6012 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CAS(Part of ZH22X12000), SAE No. 12-1, Not Shown Superseded by part number: 72186120, 167266, 79051113 |
| 9. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH22X06000), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| 10. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 11. | 2444Z2345 | [1] | ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & ZD12P01800) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of 2444Z2345), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| . . | ZD12P01800 | [1] | O-RING | KOB(Part of 2444Z2345), ID 17.8mm x OD 20.2mm, Not Shown |
| 12. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
