纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-038[01]) - CONTROL LINES, PROPEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
309 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN30V00105F1 | [1] | VALVE | KOBAssembly, Pilot (See Figure 07-008[00]) Superseded by part number: YN30V00105F2 |
| A2. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| A3. | 2420R349D155 | [2] | HOSE,6.35mm ID x 1150mm L | KOB |
| A4. | 2420R349D350 | [1] | FLEXIBLE HOSE | KOB3500mm Long (137-51/64 in) Superseded by part number: HX21E04350DX |
| A5. | 2420R349D370 | [1] | HOSE,3700.00 mm | KOB Superseded by part number: HX21E04370DX |
| A6. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of HH25X04004G2), ID 10.8mm x OD 13.2mm, Not Shown |
| A7. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH22X04006), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| A8. | ZH32X04006 | [4] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| A9. | LC52S00019P1 | [2] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100) -- Replaces YX52S00013P1 |
| A10. | YN62H01015P1 | [4] | RUBBER BAND | KOB243x33x39mm |
| A11. | HM83C10030G1 | [4] | BOLT | KOBM10x30mm |
| A12. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| A13. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| C1. | YN64H01336P1 | [1] | BLOCK | KOB |
| C2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
