纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-044[00]) - ARMREST New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
700 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN25M01235P1 | [1] | BRACKET | SM- LEFT |
| 2. | YN25M01234P1 | [1] | BRACKET | SM- RIGHT |
| 3. | YN25M01184P2 | [1] | ARMREST | KOB- LEFT |
| 4. | YN25M01185P2 | [1] | ARMREST | KOB- RIGHT |
| 5. | ZS68C08018 | [4] | SCREW | SMM08x1.25x18mm |
| 6. | ZM27C08020 | [5] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 7. | NSS | [1] | NOT SERVICED SEPARATELY | CONIncluded with Ref 6 |
