纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-080[02]) - CONDITIONING, AIR INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
576 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 2418Z1333D37 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 2600mm Length | KOBProtective Plastic |
| 5. | ZC16X02400 | [1] | CLIP | KOB |
| 6. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 7. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBM06x1.0x20mm |
| 8. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 9. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBM08x1.25x100mm |
| 10. | ZW16H08000 | [6] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 11. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 13. | YN20M01094DC | [1] | RIGID TUBE,25mm ID x 30mm OD x 2800mm Length | KOB |
| 14. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 15. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 16. | YN20M01599P1 | [1] | BRACKET | KOB |
| 17. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 19. | ZW16H10000 | [5] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 24. | 71415385 | [1] | CLIP | TOR |
| 25. | PY01P01043D3 | [7] | CABLE TIE,188mm L | KOB |
| 32. | YX91V00001F1 | [1] | COMPRESSOR,W/ Pulley | KOBAssy, See Fig. 01-080[08] |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBSK210-8 HYDRAULIC EXCAVATOR - TIER 3 ROPS (NA) ASN YQ12U4800 |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 49. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
| 57. | ZW16H06000 | [2] | WASHER | KOBID 06 x OD 15 x Th 3.2mm |
| 60. | EW02E01026D6 | [1] | CLIP | KOB Superseded by part number: 85802889 |
| 61. | YM20M01045P1 | [1] | FITTING | KOB |
| 63. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
| 64. | 12647004 | [4] | WASHER,8.15mm ID x 25mm OD x 2.5mm Thk | IMO |
| 65. | 10523404 | [4] | WASHER,6.15mm ID x 18mm OD x 2mm Thk | BAS Superseded by part number: 10523401 |
| 66. | YN20M01703P1 | [4] | RUBBER SEAL | SM |
