纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-080[01]) - CONDITIONING, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
780 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | R18T0026D7 | [1] | HOSE,12mm ID x 2300mm L | KOBID 12 x OD 22 x 2300mm |
| 4. | YN20M01414D2 | [1] | BELT, TRANSMISSION | KOB |
| 5. | ZC16X02400 | [3] | CLIP | KOB |
| 8. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 10. | ZW16H08000 | [6] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 12. | YJ21M01003D1 | [1] | FLEXIBLE HOSE | SMID 22.1 x OD 27 x 1800mm |
| 15. | ZW26X08000 | [6] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 23. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 25. | PY01P01043D3 | [7] | CABLE TIE,188mm L | KOB |
| 33. | YX20M01029F2 | [1] | PULLEY ASSY. | KOBAssy, See Fig. 01-080[08] Superseded by part number: YX20M01029F4 |
| 34. | YN20M01675P1 | [1] | CONDENSER | SM |
| 50. | NSS | [1] | NOT SERVICED SEPARATELY | CONConnector |
| 58. | 2418Z1333D13 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 100mm Length | KOBProtective Plastic |
| 68. | 84123792 | [1] | FILTER | SM |
| 69. | 84123793 | [1] | CLAMP,81mm - 84mm | SM |
| 70. | R18T0026D60 | [1] | FLEXIBLE HOSE | KOBID 12 x OD 22 x 3700mm |
| 71. | YN20M01427D8 | [1] | FLEXIBLE HOSE | SMID 22.1 x OD 27 x 3500mm |
| 72. | R18T0026D85 | [1] | HOSE,12mm ID x 1000mm L | KOBID 12 x OD 22 x 1000mm |
| 73. | YN20M01427D7 | [1] | TUBE | KOB |
| 74. | YN20M01724P1 | [1] | TUBE | KOB |
