纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-080[07]) - CONDITIONER, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
624 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 9. | LQ20M00059S009 | [1] | DUCT | SM |
| 11. | LQ20M00059S011 | [1] | BOX | SM |
| 12. | LQ20M00059S012 | [1] | BOX | SM |
| 13. | LQ20M00059S013 | [1] | RETAINER | SM |
| 16. | LQ20M00059S016 | [2] | GASKET | SM |
| 18. | LQ20M00059S018 | [1] | FLEXIBLE HOSE | SM |
| 19. | LQ20M00059S019 | [1] | FAN | SM |
| 21. | LQ20M00059S052 | [1] | WIRE HARNESS | KOB |
| 35. | LQ20M00059S035 | [3] | COVER | SM |
| 36. | LQ20M00059S036 | [2] | COVER | SM |
| 37. | LQ20M00059S037 | [1] | COVER | SM |
| 40. | LQ20M00059S040 | [1] | EVAPORATOR | SM |
| 41. | LQ20M00059S041 | [1] | HYDRAULIC VALVE | SMExpansion |
| 42. | LQ20M00059S042 | [1] | THERMOMETER | SM |
| 43. | LQ20M00059S043 | [2] | SCREW | SM |
| 44. | LQ20M00059S044 | [1] | RETAINER | SM |
| 45. | LQ20M00059S045 | [1] | RETAINER | SM |
| 46. | LQ20M00059S046 | [3] | SCREW | SM |
| 47. | LQ20M00059S047 | [22] | SCREW | SM |
